Graphite
轻便耐用
Graphite 主要特点
轻量化
弧度拼接
智能锁系统
快速安装
双面悬挂
易于维护
折叠背架可选
高亮度
半块面板
GP2.6
GP2.6 Half
GP3.1
GP3.1 Half
GP3.9
GP3.9 Half
GP2.6 (4 in 1)
GP2.6 Half (4 in 1)
- Title
- Pixel Pitch
- LED Configuration
- Max Brightness Calibrated
- Panel Dimension
- Panel Resolution (H x V)
- Weight Per Panel
- Power Consumption Max/Average
- BTU Max/Average
- Transparency
- Serviceability
- Curving (Concave & Convex)
- Viewing Angle Vertical
- Viewing Angle Horizontal
- Refresh Rate
- Gray Scale
- Scan Ratio
- Operational Temp/Humidity
- Storage Temp/Humidity
- IP Rating
- Certifications
- Max. Hanging
- Max. Stacking
- GP2.6
- 2.604mm
- SMD 1515 Black
- 1500nits
- 500mm x 1000mm x 80mm
19.7” x 39.4” x 3.1” - 192 x 384
- 9kg | 19.84lbs
- 320W / 160W
- 1100 / 500
- Solid
- Front / Rear
- Concave 5° ~ Convex 5°
- 140°
- 160°
- 7680Hz
- 16bit
- 1/16
- -20°C ~ 45°C, 10% ~ 90% RH
-4°F ~ 113°F, 10% ~ 90% RH - -40°C ~ 60°C, 10% ~ 90% RH
-40°F ~ 140°F, 10% ~ 90% RH - IP40
- CE, ETL, FCC, UKCA
- 12 panels
- 6 panels
- GP2.6 Half
- 2.604mm
- SMD 1515 Black
- 1500nits
- 500mm x 500mm x 80mm
19.7” x 19.7” x 3.1” - 192 x 192
- 5.2kg | 11.44lbs
- 160W / 80W
- 550 / 250
- Solid
- Front / Rear
- Concave 5° ~ Convex 5°
- 140°
- 160°
- 7680Hz
- 16bit
- 1/16
- -20°C ~ 45°C, 10% ~ 90% RH
-4°F ~ 113°F, 10% ~ 90% RH - -40°C ~ 60°C, 10% ~ 90% RH
-40°F ~ 140°F, 10% ~ 90% RH - IP40
- CE, ETL, FCC, UKCA
- 24 panels
- 12 panels
- GP3.1
- 3.125mm
- SMD 1515 Black
- 1500nits
- 500mm x 1000mm x 80mm
19.7” x 39.4” x 3.1” - 160 x 320
- 9kg | 19.84lbs
- 320W / 160W
- 1100 / 500
- Solid
- Front / Rear
- Concave 5° ~ Convex 5°
- 140°
- 160°
- 3840Hz
- 14bit
- 1/16
- -20°C ~ 45°C, 10% ~ 90% RH
-4°F ~ 113°F, 10% ~ 90% RH - -40°C ~ 60°C, 10% ~ 90% RH
-40°F ~ 140°F, 10% ~ 90% RH - IP40
- CE, ETL, FCC, UKCA
- 12 panels
- 6 panels
- GP3.1 Half
- 3.125mm
- SMD 1515 Black
- 1500nits
- 500mm x 500mm x 80mm
19.7” x 19.7” x 3.1” - 160 x 160
- 5.2kg | 11.44lbs
- 160W / 80W
- 550 / 250
- Solid
- Front / Rear
- Concave 5° ~ Convex 5°
- 140°
- 160°
- 3840Hz
- 14bit
- 1/16
- -20°C ~ 45°C, 10% ~ 90% RH
-4°F ~ 113°F, 10% ~ 90% RH - -40°C ~ 60°C, 10% ~ 90% RH
-40°F ~ 140°F, 10% ~ 90% RH - IP40
- CE, ETL, FCC, UKCA
- 24 panels
- 12 panels
- GP3.9
- 3.91mm
- SMD 1515 Black
- 1500nits
- 500mm x 1000mm x 80mm
19.7” x 39.4” x 3.1” - 128 x 256
- 9kg | 19.84lbs
- 320W / 160W
- 1100 / 500
- Solid
- Front / Rear
- Concave 5° ~ Convex 5°
- 140°
- 160°
- 3840Hz
- 14bit
- 1/16
- -20°C ~ 45°C, 10% ~ 90% RH
-4°F ~ 113°F, 10% ~ 90% RH - -40°C ~ 60°C, 10% ~ 90% RH
-40°F ~ 140°F, 10% ~ 90% RH - IP40
- CE, ETL, FCC, UKCA
- 12 panels
- 6 panels
- GP3.9 Half
- 3.91mm
- SMD 1515 Black
- 1500nits
- 500mm x 500mm x 80mm
19.7” x 19.7” x 3.1” - 128 x 128
- 5.2kg | 11.44lbs
- 160W / 80W
- 550 / 250
- Solid
- Front / Rear
- Concave 5° ~ Convex 5°
- 140°
- 160°
- 3840Hz
- 14bit
- 1/16
- -20°C ~ 45°C, 10% ~ 90% RH
-4°F ~ 113°F, 10% ~ 90% RH - -40°C ~ 60°C, 10% ~ 90% RH
-40°F ~ 140°F, 10% ~ 90% RH - IP40
- CE, ETL, FCC, UKCA
- 24 panels
- 12 panels
- GP2.6 (4 in 1)
- 2.604mm
- 4 in 1 common anode
- 1500nits
- 500mm x 1000mm x 80mm
19.7” x 39.4” x 3.1” - 192 x 384
- 8.6kg | 18.96lbs
- 250W / 125W
- 850 / 390
- Solid
- Front / Rear
- Concave 5° ~ Convex 5°
- 140°
- 160°
- 7680Hz
- 16bit
- 1/16
- -20°C ~ 45°C, 10% ~ 90% RH
-4°F ~ 113°F, 10% ~ 90% RH - -40°C ~ 60°C, 10% ~ 90% RH
-40°F ~ 140°F, 10% ~ 90% RH - IP40
- CE, ETL, FCC, UKCA
- 12 panels
- 6 panels
- GP2.6 Half (4 in 1)
- 2.604mm
- 4 in 1 common anode
- 1500nits
- 500mm x 500mm x 80mm
19.7” x 19.7” x 3.1” - 192 x 192
- 5.1kg | 11.24lbs
- 125W / 62W
- 425 / 195
- Solid
- Front / Rear
- Concave 5° ~ Convex 5°
- 140°
- 160°
- 7680Hz
- 16bit
- 1/16
- -20°C ~ 45°C, 10% ~ 90% RH
-4°F ~ 113°F, 10% ~ 90% RH - -40°C ~ 60°C, 10% ~ 90% RH
-40°F ~ 140°F, 10% ~ 90% RH - IP40
- CE, ETL, FCC, UKCA
- 24 panels
- 12 panels
配件
和Oracle CloudWorld合作是一次激动人心的经历。我为我们的团队LMG 和 BrainHub,将设计变为现实所做的努力感到非常自豪。同时,在现场安装雷迪奥屏幕带来了与众不同的体验,轻巧且易于维护的安装方式正在改变游戏规则。
