Meru
あらゆる空間にフィットする柔軟性
Meru Key Features
EMCクラスB認証取得
屋内使用対応
簡単な設置・メンテナンス
スタイリッシュな壁掛けデザイン
高精度な構造
Downloads
Specs
MR1.9
MR1.9 Half
MR2.6
MR2.6 Half
- Title
- Pixel Pitch
- LED Configuration
- Max Brightness Calibrated
- Panel Dimension
- Panel Resolution (H x V)
- Weight Per Panel
- Power Consumption Max/Average
- BTU Max/Average
- Transparency
- Serviceability
- Viewing Angle Vertical
- Viewing Angle Horizontal
- Refresh Rate
- Gray Scale
- Scan Ratio
- Operational Temp/Humidity
- Storage Temp/Humidity
- IP Rating
- Certifications
- MR1.9
- 1.9mm
- 1000nits
- 500mm x 1000mm x 48mm
19.69” x 39.37” x 1.89” - 256 x 512
- 14.8kg | 32.6lbs
- 220W / 110W
- 760 / 380
- Solid
- Front
- 160°
- 160°
- 7680Hz
- 15bit
- -20°C ~ 45°C, 10% ~ 90% RH
-4°F ~ 113°F, 10% ~ 90% RH - -40°C ~ 60°C, 10% ~ 90% RH
-40°F ~ 140°F, 10% ~ 90% RH - IP40
- CE, FCC, ETL, UKCA, RoHS, WEEE
- MR1.9 Half
- 1.9mm
- 1000nits
- 500mm x 500mm x 48mm
19.69” x 19.69” x 1.89” - 256 x 256
- 7.4kg | 16.3lbs
- 110W / 55W
- 380 / 190
- Solid
- Front
- 160°
- 160°
- 7680Hz
- 15bit
- -20°C ~ 45°C, 10% ~ 90% RH
-4°F ~ 113°F, 10% ~ 90% RH - -40°C ~ 60°C, 10% ~ 90% RH
-40°F ~ 140°F, 10% ~ 90% RH - IP40
- CE, FCC, ETL, UKCA, RoHS, WEEE
- MR2.6
- 2.6mm
- 1200nits
- 500mm x 1000mm x 48mm
19.69” x 39.37” x 1.89” - 192 x 384
- 14.8kg | 32.6lbs
- 280W / 140W
- 960 / 480
- Solid
- Front
- 160°
- 160°
- 7680Hz
- 15bit
- -20°C ~ 45°C, 10% ~ 90% RH
-4°F ~ 113°F, 10% ~ 90% RH - -40°C ~ 60°C, 10% ~ 90% RH
-40°F ~ 140°F, 10% ~ 90% RH - IP40
- CE, FCC, ETL, UKCA, RoHS, WEEE
- MR2.6 Half
- 2.6mm
- 1200nits
- 500mm x 500mm x 48mm
19.69” x 19.69” x 1.89” - 192 x 192
- 7.4kg | 16.3lbs
- 140W / 70W
- 480 / 240
- Solid
- Front
- 160°
- 160°
- 7680Hz
- 15bit
- -20°C ~ 45°C, 10% ~ 90% RH
-4°F ~ 113°F, 10% ~ 90% RH - -40°C ~ 60°C, 10% ~ 90% RH
-40°F ~ 140°F, 10% ~ 90% RH - IP40
- CE, FCC, ETL, UKCA, RoHS, WEEE
All specification values given are per panel. The specifications are for reference only, actual values may vary. The max. hanging amount is only valid when official ROE Visual hardware parts are used. The safety factor is 8. Climbing is only allowed if stated in the panel manual and only following the rules given therein. The max. stacking amount is only valid when official ROE Visual hardware parts are used and when sufficient ballast is applied – following the rules as stated in the panel manual and/or structural report.
