Black Pearl
比類のないレンズ表現力



Black Pearl BP2V2
映画やテレビに適した高性能LEDビジョン
BlackPearlの主な特徴
頑丈なマグネシウム合金フレーム
マグネット式組立
エッジ保護
クリエイティブモジュール
インテリジェントモジュールストレージ校正
高い電力供給効率
屋内活用
BP2 - 2.84, BP3 - 3.91mm
スペック
BP2V2
- Title
- Pixel Pitch
- LED Configuration
- Max Brightness Calibrated
- Panel Dimension
- Panel Resolution (H x V)
- Weight Per Panel
- Power Consumption Max/Average
- BTU Max/Average
- Transparency
- Serviceability
- Curving (Concave & Convex)
- Viewing Angle Vertical
- Viewing Angle Horizontal
- Refresh Rate
- Gray Scale
- Scan Ratio
- Operational Temp/Humidity
- Storage Temp/Humidity
- IP Rating
- Certifications
- Max. Hanging
- Max. Stacking
- BP2V2
- 2.84mm
- SMD 1515 Black
- 1500nits
- 500mm x 500mm x 90mm
19.69” x 19.69” x 3.54” - 176 x 176
- 9.35kg | 20.61lbs
- 190W / 95W
- 630 / 300
- Solid
- Front
- Concave 10° ~ Convex 0°
- 140°
- 140°
- 7680Hz
- 16bit
- 1/8
- -20°C ~ 45°C, 10% ~ 90% RH
-4°F ~ 113°F, 10% ~ 90% RH - -40°C ~ 60°C, 10% ~ 90% RH
-40°F ~ 140°F, 10% ~ 90% RH - IP40
- CE, ETL, FCC, WEEE
- 20 panels
- 12 panels
All specification values given are per panel. The specifications are for reference only, actual values may vary. The max. hanging amount is only valid when official ROE Visual hardware parts are used. The safety factor is 8. Climbing is only allowed if stated in the panel manual and only following the rules given therein. The max. stacking amount is only valid when official ROE Visual hardware parts are used and when sufficient ballast is applied – following the rules as stated in the panel manual and/or structural report.

付属品
